Description
SpecificationsKV: 2750. 3800. 4600Configuration: 9N12PNo.of Cells(Lipo): 4-6SRotor: N52H arc magnetsStator: 0.15mm Nippon silicon steelShaft: SUS 420Bearings: NSK 5x2x2.5Wire AWG: 30 AWG wire 10cm lengthBell cap: 7075 AlBase casing: 7075 AlProp Adapter Shaft Thread: M 1.5Bolt Pattern: M2 9X9Weight: 8.6g with 100mm length SR Wires
Brother Hobby TC-1404 Ultralight drone brushless motor: Specification – 4600KV. Configuration: KV3800. Dimensions (mm): Stator Length = 14. Height = unknown. Weight including cable (g) = 8.6 (100mm). Motor dimensions (mm): Ø18.2 x 16. Number of cells (Lipo) = 4S. Magnet type: N52H. Propeller size: 3 inches. ESC type: 4S. Output (A) = 1.0A. Internal resistance (mΩ) unknown.
Product Highlights:04 Key Advantages:01. Solid construction featuring aerospace-grade 7075 aluminum (hard anodizing cover); resistant to scratching without leaving a trace.02. Heat-treated steel alloy shaft; wear-resistant and capable of tolerating crashes.
Features:Free and quiet flight experience: Our motor boasts 02 smooth internal Japanese NMB bearings. providing a silky-smooth running performance.
Design:0.1mm ultra-thin N52H high-performance rare silver wire non-oriented silicon steel. earth arc magnet design. This ensures:* Low risk of overheating even when flying at high throttle for an extended period (100% throttle).* Strong power output that remains consistent throughout the flight. even at high throttle settings.* Silky-smooth performance with strong power delivery.
Packaging List:Motor x 1M2 x 5 (base screw)M2 x 4 (prop screw)
