Foxeer 10x Zoom 700TVL CMOS Camera SPECIFICATIONS
Use: Vehicles & Remote Control Toys
Upgrade Parts/Accessories: Adapter
Tool Supplies: Tools
Technical parameters: Value 2
Size: As
Remote Control Peripherals/Devices: Remote Controller
Recommend Age: 12+y
RC Parts & Accs: Receivers
Origin: Mainland China
Model Number: 1832
Material: Metal
Four-wheel Drive Attributes: Assemblage
For Vehicle Type: Airplanes
Brand Name: uuustore
Foxeer 10x Zoom 700TVL Effio DSP CMOS Camera PWM Controll For FPV UAV Aerial Photography
700TVL 10X zoom camera specialized for FPV. adopt CMOS image sensor and Effio DSP. have good WDR function. low illumination is up to 0.001Lux at B/W mode. PWM signal control zoom.
| Solution | 1/3” Sony CCD+Effio DSP |
| Effective Pixel | 976(H) x 596(V) |
| Tv System | PAL/NTSC Optional |
| Resolution | 700TVL |
| Min. Illumination | Color: 0.01Lux; B/W: 0.001Lux |
| Digital Electronic Zoom | No |
| WDR | Yes |
| Digital Noise Reduction | Yes |
| Frame Accumulated | Yes |
| Focus Length | 3.9~38mm |
| Optical Focus | 10X |
| Focus | Zoom controlled by ground controller |
| White Balance | Auto |
| Iris | Auto |
| S/N Ratio | >60dB(Enhanced) |
| Electronic Shutter | PAL:1/50~1/10000 seconds NTSC:1/60~1/12000 seconds |
| Language | English |
| Power Supply | DC 12V |
| Work Temperature | 0~ 70°C |
| Size | 65mm*35mm*43mm |
| Weight | 116g |
| Package Includes | 1 x camera; 1 x cable |
