Description

Happymodel 2.4GHz ELRS Receiver Mini Micro EPW6 PWM Output

Check out all of our other HappyModel products! Also, take a look at all of our Radio Receivers, and all of our ELRS-compatible products!

Specifications:

• Item: Happymodel EPW6 TCXO 2.4GHz PWM receiver
• ESP8285, SX1280/1281
• Antenna connector: IPEX MHF 1/U.FL
• 6x PWM outputs
• RF Frequency: 2.4GHz (2400~2480MHz)
• Telemetry power: 12dbm
• Receiver protocol: PWM or CRSF
• Input voltage: +5v~8.4v
• PCB size: 19mm x 17.5mm
• Weight: 1.49g / antenna
• Firmware
• Target option 1: Generic ESP8285 6xPWM 2.4Ghz RX
• PWM receiver via 1~6 PWM outputs
• Target option 2: HappyModel_EP_2400_RX
• CRSF Serial receiver via TX and RX
• Firmware update via WIFI

Bind Procedure:
1) Supply power to the EPW6 RX, wait until the Green LED on the RX is off, immediately turn off the power, and then repeat the above steps again. When the RX is powered on for the third time, the Green LED light will start to double-flash, which means that the RX enters the binding mode
2) Get into the menu of ELRS.LUA V2.0 version from your radio transmitter and then press BIND, the Green LED on the RX module will turn solid if bound successfully.

Receiver LED status meanings:
LED solid means bind successful or Connection established; LED double-flash means in bind mode; LED flash slowly means no signal connection from the TX module; LED flash fast means in WIFI hotspot mode, you can connect the WIFI of the RX and upgrade the firmware of the RX via visit 10.0.0.1 from the web browser (password: expresslrs)

Package Contents:

• 1x HappyModel EPW5 2.4GHz ELRS PWM Receiver
• 2 x 2.4GHz antenna
• 1x 6pin 2.54mm
