Description
Precision Control Through Advanced Encoder Technology
The AS5048A encoder-equipped brushless gimbal motor delivers superior precision and smooth motion for professional 3-axis stabilization systems.
Encoders are high-accuracy magnetic sensors integrated into each motor, allowing the gimbal to track motor position in real time. This results in greater stability, faster torque response, and up to 5× longer operating time compared to standard non-encoder gimbals.
The combination of active motor-driven stabilization and passive inertial balance ensures ultra-smooth performance, improved accuracy, and enhanced control for both aerial and handheld camera platforms.
Key Features
Simplified gimbal tuning – minimal calibration required
Up to 5× longer runtime compared to non-encoder systems
Dual IMUs for higher stabilization precision
Instant torque increase for demanding motion angles
Integrated AS5048A encoder chip for precise real-time feedback
Energy-efficient brushless design for stable and consistent performance
Specifications
Model: GM5208
Motor Out Diameter: Ф63±0.05mm
Configuration: 12N/14P
Motor Height: 30.7±0.2mm (Included with Encoder housing)
Hollow Shaft(OD): Ф15-0.008/-0.012 mm
Hollow Shaft(ID): Ф12+0.05/0 mm
Wire Length: 610±3mm
Cable AWG: #24
Motor Weight: 209±0.5g
Wire plug: 2.5mm dupont connector
No-load current: 0.09±0.1 A
No-load volts: 20V
No-load Rpm: 456~504 RPM
Load current: 1A
Load volts: 20V
Load torque(g): 1800-2500
Motor internal resistance: 15.2Ω±5%（Resistance varies with temperature）
High voltage test: DC500V 10mA @1sec
Rotor housing runout: ≤0.1mm
Steering (axle extension): clockwise
High-low temperature test:
High temperature: Keep at 60℃ for 100 hours, and the motor can work normally after 24 hours at room temperature
Low temperature: Keep at -20℃ for 100 hours, and the motor can work normally after 24 hours at room temperature
Maximum power: ≤40W
Working Voltage: 3-5S
Working temperature: -20~60℃;10~90%RH
Compatible Sliprings
iPower Gimbal Motor Slipring – OD 7.9mm
iPower High Current Gimbal Metal Slipring – OD12.5mm
Packing List
3 x GM5208-12 Gimbal Motor with AS5048A Encoder & Magnet
1 x Alexmos 32BIT BGC Board Encoder version without alum case
1 x Connecting cables set
