Description
Reefs Beast 1000 Waterproof Digital 1/5 Scale Brushless Servo. This monster 1/5 scale servo is capable of up to 1080oz-in. at 8.4V and 0.08/60° sec. Package includes one servo, two servo horns and hardware.
NOTE: BEC is not required but recommended for maximum performance.
Features:
- High torque high speed brushless servo
- Magnetic angle sensor
- Waterproof
- Pulse width modulation control
- Includes Reefs single and double servo horn
Specifications:
- Voltage: 4.8-8.4V
- Waterproofing: 7 Point Seal
- Mechanical Angle: No Limit
- Material: Steel Gears/CNC Aluminum Casing
- Bearing Type: 5 Ball Bearing
- Wires: 22AWG
- Weight: 10oz (285g)
- Dimension: 2.59×1.18×2.32in (LxWxH)
- Torque:
- 6V: 800oz-in
- 7.4V: 900oz-in
- 8.4V: 1080oz-in
- Speed:
- 6V: 0.11/60° sec
- 7.4V: 0.095/60° sec
- 8.4V: 0.08/60° sec
- Spline: 15T
- Dead Band Width: 2uSec
CA Residents Prop 65 Warning WARNING: This product can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov Details…
This product was added to our catalog on August 25, 2021
