RunCam Link Digital FPV Air Unit (Unit Only)
The HDL FPV Transmission system and the FPV Air units are equipped with eight frequency channels, which allow up to eight drones to fly simultaneously. Each operator has an exclusive channel. This helps to reduce cross-interference and provide an optimal racing experience. Users can wirelessly connect their DJI FPV Air Unit to the DJI FPV Remote Controller without having to purchase additional receivers. This reduces flight preparation time significantly.
See all of our RunCam Cameras & Air units!
Parameters
| Model | RunCam LINK Phoenix HD Kit |
| Frequency | 5.725-5.850 GHz |
| Max. Distance | FCC/SRRC: <4 km & CE: <0.7 km |
| Power | 7.4-26.4 V@ 4-9W |
| Dimensions | 29×29×13 mm |
| Net Weight | 19.5 g |
| Model | RunCam Phoenix HD |
| Image Sensor | 1/2” |
| Resolution | 1280*720@60fps |
| LENS | FOV D:157° H:133° V:72° |
| Shutter | Rolling Shutter |
| Coaxial Cable | 120 mm |
| Dimensions | L19mm*W19mm*H23.5mm |
| Net Weight | 7.5g |
RunCam Link Phoenix HD Kit Manual
English
Air Unit Phoenix HD Kit Manual
English
