Description
The SURPASS HOBBY C2204 Brushless Motor is a high-performance. cost-effective power solution designed specifically for RC 3D fixed-wing airplanes. including Cessna-style models. Available in 1200KV and 1400KV variants. it delivers powerful thrust. smooth throttle response. and efficient energy conversion for stable and agile flight.
Built with CNC-machined 6061-T6 aluminum and featuring a 14-pole / 12-slot high-torque design. this motor ensures durability. thermal stability. and extended run time even under demanding conditions. Whether you’re flying aerobatics or cruising in the park. the C2204 provides consistent and reliable performance.
Key Features:
-
Optional KV Ratings: 1200KV / 1400KV
-
14-pole / 12-slot high-torque stator design for increased efficiency and responsiveness
-
CNC machined 6061-T6 aluminum housing for superior heat dissipation
-
High-purity copper windings for maximum efficiency
-
Oversized high-RPM ABEC-5 bearings for low-friction operation
-
Precision-balanced rotor ensures smooth. vibration-free performance
-
Ultra-thin 0.2mm stator laminations for minimal energy loss
-
Optimized for energy conversion and extended flight time
Specifications:
| Parameter | Details |
|---|---|
| Model | SURPASS C2204 |
| KV Rating | 1200KV / 1400KV (Optional) |
| Max Power | 140W |
| Voltage Range | 7V–15V |
| Max Current | 11A |
| Idle Current (IO) | 0.4A |
| Internal Resistance | 0.368Ω |
| Motor Dimensions | Ø28 × 22mm |
| Stator Size | 2204 |
| Shaft Size | M3 (not listed but assumed standard) |
| Weight | 28.1g |
| Recommended Props | 7.5×3.5 / 8×4 / 9×5 inch |
| Connectors | 3.5mm Gold-Plated Banana Plugs |
Package Includes:
-
1 × SURPASS C2204 Brushless Motor
-
Mounting Accessories (if included)
Package Size & Weight:
-
Box Dimensions: 8 × 6.5 × 5cm
-
Gross Weight: 59g
Ideal for fixed-wing trainers. aerobatic 3D planes. and lightweight Cessna-style RC aircraft. the C2204 combines premium materials with precise engineering—giving you smooth. efficient. and powerful flight at a great value.
