Description
Axisflying 640 Thermal Imaging Camera Specs
| Feature | Specification |
|---|---|
| Model | GE-3F |
| Resolution | 640×512 |
| Detector type | Vanadium Oxide Uncooled Infrared Focal Plane Detector |
| Frame rate | 60fps |
| Pixel spacing | 12um |
| NETD | 40mk |
| Response band | 8~14um |
| Lens spec | 9.1mm F1.0 / 13.5mm F1.0 / 18mm F1.1 |
| FOV (H*V) | 9.1mm: 48.7°x38.6°. 13.5mm: 31.9°x25.7°. 18mm: 24.2°x19.5° |
| Whether to image | Yes |
| False color type | White hot |
| Input Voltage | 4.5-18V |
| Output type | CVBS |
| Analog Video | PAL |
| Module volume (excluding lens) | 21*21 |
| Weight (without lens) | <8g |
| Operating temp | -40°C~+80°C |
| Storage temp | -50°C~+85°C |
| Brand | AXISFLYING |
s
- High-Resolution Imaging: 640×512 pixel Vanadium Oxide Uncooled Infrared Detector ensures detailed and sharp thermal images.
- Lightweight Design: Weighs less than 8 grams (without lens). making it highly portable and ideal for applications where every gram counts.
- Easy Integration: Compact module dimensions of 21*21 for straightforward incorporation into a variety of systems.
- Energy-Efficient: Operates on a low input voltage range of 4.5-18V for eco-friendly and prolonged use.
- Adaptive Lens Options: Multiple lens specifications (9.1mm. 13.5mm. 18mm) to suit different field of view requirements.
- Smooth Frame Rate: Captures fluid motion at 60 frames per second. crucial for both live monitoring and detailed analysis.
- Enhanced Sensitivity: Features a NETD of 40mk. capturing subtle temperature differences effectively.
- White Hot Imaging: The false color ‘white hot’ mode enables easy interpretation of heat signatures.
- Durable: Operates reliably within a temperature range of -40°C to +80°C and stores safely between -50°C to +85°C.
Axisflying Thermal Camera for Drone
Axisflying 640 Thermal Imaging Camera – High-Resolution 640×512 60FPS 40MK Thermal Camera for FPV Drone Camera
Main advantages include a compact size. lightweight design. and ease of integration for the 640×512 pixel thermal imaging camera with high resolution and low power consumption.
The Axisflying 640 Thermal Imaging Camera features a high-resolution sensor with a resolution of 640×512 pixels. It has a frame rate of 60 frames per second and a pixel spacing of 12um. The camera uses an uncooled vanadium oxide focal plane detector. making it suitable for FPV drone applications. The NETD is 40mK. and the response band is 8-14pm. The lens specifications include a 9mm. 13.5mm. and 18mm options. with fields of view (H*V) of 48.78×38.6. 31.9×25.70. and 24.2×19.58. respectively. The camera can output images in both black hot and white hot color modes.
